This is an A60 Watertight Emergency Escape Hatch.
The Libra WRH Series is a robust and heavy duty hatch type.
This A60 Hatch is suitable to withstand A60 fire requirements.
It is Watertight and is designed to withstand water pressure from both sides.
They are pressure tested to a given pressure together with the class authorities.
This hatch is available in steel material only.
This hatch is Type Approved certified by DNV-GL with regards to Fire and Weather.
Maximum size according to our certificates is: CO (Clear Opening) = 800 x 800mm (length x width).
Other sizes can be discussed upon request.
- Moving parts made of high quality stainless steel
- Adjustable moving parts
- Adjustable frame brackets on request
- Angle profile frame available
- Quick-acting or wheel-operated locking system
- 100 mm corner radius
- Size according to request
- Standard surface treatment – sandblasted and primed.
- Special surface treatment is available upon request
